Metadata, Versioning & Compatibility in OTA Firmware Updates

As your OTA system matures, one aspect becomes critical for reliability and long-term support: metadata.

A firmware update isn’t just binary data — it carries a version, a target device, a stack dependency, maybe even a hardware revision. Without this metadata, your device risks:

• Running incompatible firmware
• Downgrading to older (potentially vulnerable) builds
• Misinterpreting what’s installed vs. what’s in flash

This episode will dive into:

• Metadata structure
• Firmware versioning strategies
• Downgrade protection
• BLE stack compatibility (e.g. SoftDevice in Nordic, FUS in STM32WB)
• Real-world examples (Fitbit, Apple Watch, STM32, Nordic)

What is OTA Metadata?

Firmware metadata is a header or external descriptor that carries update context.

Common fields in firmware metadata:

Example OTA Metadata Structure (C-style)

typedef struct {
    uint32_t magic;              // e.g., 0xA5A5A5A5
    uint32_t version;            // e.g., 0x00010002 → v1.2
    uint32_t hw_id;              // Target hardware model
    uint32_t size;               // Image size in bytes
    uint32_t crc32;              // Optional lightweight check
    uint8_t  sha256[32];         // Strong integrity check
    uint32_t ble_stack_ver;      // Required BLE stack version
    uint32_t flags;              // e.g., test build, encrypted, etc.
    uint8_t  signature[64];      // ECC signature of hash
} ota_metadata_t;

Versioning Strategies

Use structured versioning to track firmware progression.

Semantic Versioning (recommended):

Major.Minor.Patch
→ Example: 2.4.1 = major upgrade v2, feature set 4, bugfix 1

• Increment Patch for bugfixes
• Increment Minor for feature additions
• Increment Major for breaking changes (e.g., BLE protocol change)

Preventing Downgrade Attacks

Devices should reject older firmware versions, unless in debug/test mode.

if (incoming_version <= current_version) {
    reject_ota("Downgrade not allowed");
}

Used In:

• Apple Watch: Version rollback is prevented by iOS OTA manager
• STM32WB + SBSFU: Metadata contains version_min flag to block lower versions
• Nordic Secure DFU: Version stored in bootloader-protected flash region

BLE Stack Compatibility Checks

BLE stacks (SoftDevice, FUS, etc.) can break compatibility between app and OTA logic.

Your OTA metadata should:

• Contain required stack version (e.g., 0x010003 for SoftDevice S132 v1.3)
• Reject update if device has incompatible stack
• Optionally trigger BLE stack update before firmware OTA

STM32WB Example:

• BLE stack (FUS) is separate from the application
• Application metadata must declare compatible FUS version
• FUS updates must be OTA’d in two stages

if (metadata.fus_version_required > current_fus_version) {
    trigger_fus_update();
}

External OTA Manifest (App or Server Side)

Some systems don’t embed all metadata in the firmware binary — instead, they use a sidecar JSON file or OTA manifest.

{
  "version": "1.4.2",
  "device_model": "WB-M1",
  "image_size": 98304,
  "sha256": "5f2c...78d",
  "ble_stack_version": "0.7.5",
  "min_supported_version": "1.2.0"
}

Used by:

• Fitbit and Garmin apps (manifest controls compatibility)
• Oura Ring OTA
• Custom mobile BLE updaters using React Native or Flutter

Best Practices

Real-World Metadata Behavior
