Ensuring Data Integrity and Handling Failures in OTA Firmware Updates

In previous episodes, we explored OTA architecture, partitioning, and security. But even with perfect encryption and boot validation, there’s another crucial layer: ensuring data integrity and safely handling failures — especially in constrained BLE environments.

If a firmware update is interrupted or corrupted, and your system doesn’t catch it in time, you risk bricking the device.

This episode will break down:

How to detect data corruption
How to fail gracefully and recover
How real-world devices like Fitbit and STM32WB do it
Techniques like CRC, SHA, status flags, watchdog resets, and rollback

What Can Go Wrong in OTA?

Risk	Example Case
Packet loss or corruption	BLE dropout mid-transfer
Power loss during write/swap	Battery dies mid-flash
Partial update	Transfer aborted but metadata was updated
Flash write errors	Misaligned writes or ECC failure
Wrong or tampered firmware	Firmware modified post-download

Verifying Data Integrity

Data integrity checks ensure what was received is what was expected — before flashing or booting.

1. CRC (Cyclic Redundancy Check)

Lightweight and fast
Usually CRC16 or CRC32
Verified during:
- End of OTA transfer
- Bootloader check

bool crc_check_passed = calculate_crc32(image) == expected_crc32;

Example:

Fitbit and Nordic DFU protocols attach CRC32 to each chunk and to the entire image.

2. SHA-256 Hash Check

Stronger, cryptographic hash
Slower, but more robust
Used for:
- Final image validation before reboot
- Signature verification

sha256(image, length, hash_out);
if (memcmp(hash_out, expected_hash, 32) != 0) {
    return IMAGE_CORRUPTED;
}

Example:

STM32WB + SBSFU, ESP32 Secure Boot, and MCUBoot all use SHA-256 for validating update images.

3. Signature Check = Integrity + Authenticity

If your update is signed (ECC/RSA), the signature validates both the integrity and authenticity of the image.

If SHA-256 hash fails, the signature check fails.
If someone tampers with the firmware post-signing, bootloader blocks execution.

Handling OTA Failures

OTA should never leave your device in a broken state. That’s where rollback and retry mechanisms come in.

1. Watchdog Timers for First Boot

Start a watchdog timer after OTA reboot
If the app crashes or fails to clear the watchdog, bootloader flags the update as failed

start_watchdog(5_seconds);
app_code();  // if this hangs, watchdog triggers reboot

Example:

MCUBoot uses a “pending” state. Only after the first boot succeeds does the firmware become “permanent”.
Fitbit uses a boot signal sent from app to bootloader via shared flash flag.

2. Boot Status Flags in Flash

Use a reserved flash page or option byte to store OTA status:
- OTA_PENDING
- OTA_SUCCESS
- OTA_FAILED

Bootloader Logic:

if (ota_status == OTA_PENDING) {
    if (firmware_valid()) {
        set_ota_status(OTA_SUCCESS);
    } else {
        rollback_to_previous_image();
    }
}

3. Rollback to Previous Image

Devices with dual-slot partitioning (Episode 3) can revert if the new image fails validation or boot.

Steps:

Keep last known good firmware in App Slot A
OTA installs new image to Slot B
If Slot B fails, bootloader rolls back to Slot A

Example:

Fitbit, Oura Ring, and Amazon Echo Buds all support rollback using similar logic.

4. Resume Interrupted Updates

BLE transfers are fragile. Your OTA logic should:

Allow resume from last good chunk
Validate each chunk’s CRC/hash
Avoid rewriting already validated blocks

Nordic DFU Example:

// If transfer fails after 62%, reconnect resumes from chunk 63
device responds with last received offset → app continues

Practical Design Tips

Tip	Why It Helps
Always verify hash or CRC before boot	Prevents corrupted firmware from being executed
Use boot status flags	Tracks update status across reboots
Don’t erase old firmware until success	Enables rollback
Use watchdog timer after OTA	Catches faulty first boots
Use power-fail-safe flash writing logic	Avoids half-burned sectors
Keep metadata separate from OTA partitions	Prevents accidental overwrite

Real-World Snapshot: Fitbit OTA

OTA update via BLE
Each packet validated with CRC
Final image validated with SHA-256
Bootloader only swaps if update status is OK
Rollback on boot error or hash mismatch
Watchdog used for first-boot crash detection

Failure Handling in STM32WB (with SBSFU)

SBSFU marks OTA status in a reserved flash area
Verifies firmware header (hash + signature)
Boots new image only if verified
Resets to old image if first boot fails or watchdog triggers
Optional: tamper-detection logic or hardware reset control

Conclusion

A secure OTA update is not just about encryption — it’s about ensuring the firmware was delivered, validated, and installed safely. If something fails, your device must recover gracefully, not silently fail or brick.

Handling failures is a mark of a mature, production-grade OTA system.
