Introduction

Your Thread devices are now publishing sensor data to an MQTT broker. The next step is to visualize this data in real time. In this episode, we’ll use Node-RED to build a live dashboard. It will show data from Thread-based sensors like temperature or humidity.

What is Node-RED?

Node-RED is a low-code, flow-based development tool for wiring together hardware devices, APIs, and online services. It’s perfect for building dashboards quickly using MQTT data.

System Overview

• STM32WB Thread Device → Sends data over CoAP to Border Router
• Border Router → Publishes to MQTT Broker
• Node-RED → Subscribes to MQTT topics and displays data

Installing Node-RED

On your Border Router (or separate Linux server), install Node-RED:

sudo npm install -g --unsafe-perm node-red
node-red

Access it via your browser: http://localhost:1880

Setting Up MQTT in Node-RED

1. Drag an MQTT IN node to the flow editor.
2. Configure the broker (e.g., mqtt://localhost:1883)
3. Set the topic to: thread/sensor/temp
4. Connect it to a gauge node from the Dashboard palette.

Creating a Simple Flow

Your basic flow will look like this:

[MQTT IN] → [Function Node (parse data)] → [Gauge (Dashboard)]

Example function node to parse raw CoAP payload:

msg.payload = parseFloat(msg.payload.trim());
return msg;

Dashboard Setup

• Install the Dashboard module: node-red-dashboard
• Access the UI at: http://localhost:1880/ui
• Add graphs, charts, and widgets to show temperature trends over time

Expanding the Dashboard

You can extend the dashboard with:

• Historical line charts for temperature
• Toggle switches to send control commands (e.g., LED ON/OFF via MQTT)
• Alerts when thresholds are crossed

Conclusion

With Node-RED and MQTT, you’ve built a responsive dashboard for your Thread network. This visual layer completes the IoT stack—from sensor to cloud to user interface. In the next episode, we’ll explore adding secure OTA (Over-the-Air) firmware updates for STM32WB in a Thread network.
