DTLS and PSK: Enhancing CoAP Security

Introduction

Security is a core part of any IoT application. In this episode, we’ll explore securing CoAP communication between two Thread nodes. We will use DTLS (Datagram Transport Layer Security) with Pre-Shared Keys (PSK). This ensures your data, like sensor readings or control messages, cannot be intercepted or tampered with.

Why DTLS?

DTLS is the UDP-compatible version of TLS (used in HTTPS). Since Thread uses UDP for communication (including CoAP), DTLS fits naturally to provide encryption, message integrity, and optional authentication.

Approach: DTLS with Pre-Shared Keys

We’ll configure both Thread devices to use a matching PSK. The DTLS session will be established before CoAP messages are exchanged.

Required Components

STM32WB with OpenThread and MbedTLS enabled.
CoAP over secure DTLS session.
Matching PSK and identity on both nodes.

Setting Up DTLS on the Server (Device B)

Configure the DTLS context and bind it to a socket that listens for incoming secure connections:


static const uint8_t kPsk[] = "hardfault_secure_key";
static const char *kPskIdentity = "client1";

void SetupDtlsServer() {
    otPlatDtlsPskSet(otInstance, kPskIdentity, kPsk, sizeof(kPsk));
    otPlatDtlsListen(otInstance, DtlsReceiveHandler, NULL);
}

void DtlsReceiveHandler(void *aContext, otMessage *aMessage, const otMessageInfo *aMessageInfo) {
    // Process decrypted CoAP request
    HandleLedRequest(aContext, aMessage, aMessageInfo);
}

Setting Up DTLS on the Client (Device A)

The client must also set the same PSK before initiating a CoAP request:


void SetupDtlsClient() {
    otPlatDtlsPskSet(otInstance, "client1", (const uint8_t *)"hardfault_secure_key", strlen("hardfault_secure_key"));
}

void SendSecureCoapRequest() {
    SetupDtlsClient();
    // Initiate CoAP POST over DTLS
    RequestTempData(&peerAddr);  // Your existing CoAP function
}

Integration with CoAP

Once DTLS is set up and connected, CoAP messages are automatically encrypted and authenticated when sent over that connection.

Debugging Tips

Ensure both PSK and identity match on both nodes.
Use logging (e.g., UART or RTT) to confirm DTLS handshake success.
Check for DTLS-related errors using otError codes.

Security Benefits

Encryption of data in transit.
Authentication using PSK to prevent spoofing.
Message integrity validation to prevent tampering.

Conclusion

By adding DTLS with PSK, you’ve now secured CoAP-based communication between Thread nodes, enabling encrypted and trusted messaging. In the next episode, we’ll build on this. We will create a simple Thread-based sensor dashboard. It will use a border router and an MQTT bridge.
